Part Number |
Hose I.D. (in.) | Thread | Hex | Stem I.D. | Fitting Length | C.O. Cutoff | Nut Hex | Description |
203-202 |
3/16 | 1/8-27 | - | 0.125 | 1.955 | 1.05 | 1/2 | - |
203-204 |
3/16 | 1/4-18 | - | 0.125 | 2.325 | 1.46 | 11/16 | - |
204-202 |
1/4 | 1/8-27 | - | 0.156 | 2.216 | 1.226 | 1/2 | - |
204-204 |
1/4 | 1/4-18 | - | 0.156 | 2.445 | 1.44 | 11/16 | - |
204-206 |
1/4 | 3/8-18 | - | 0.156 | 2.595 | 1.625 | 13/16 | - |
204-208 |
1/4 | 1/2-14 | - | 0.156 | 2.785 | 1.795 | 7/8 | - |
205-204 |
5/16 | 1/4-18 | - | 0.234 | 2.453 | 1.463 | 11/16 | - |
205-206 |
5/16 | 3/8-18 | - | 0.234 | 2.61 | 1.625 | 13/16 | - |
206-204 |
3/8 | 1/4-18 | - | 0.218 | 2.59 | 1.605 | 11/16 | - |
206-206 |
3/8 | 3/8-18 | - | 0.296 | 2.59 | 1.625 | 13/16 | - |
206-208 |
3/8 | 1/2-14 | - | 0.296 | 2.78 | 1.81 | 7/8 | - |
208-206 |
1/2 | 3/8-18 | - | 0.406 | 2.835 | 1.605 | 1 | - |
208-208 |
1/2 | 1/2-14 | - | 0.406 | 3.035 | 1.8 | 1 | - |
210-212 |
5/8 | 3/4-14 | - | 0.5 | 3.08 | 1.855 | 1-5/16 | - |
212-208 |
3/4 | 1/2-14 | - | 0.625 | 3.125 | 1.89 | 1-5/16 | - |
212-212 |
3/4 | 3/4-14 | - | 0.625 | 3.135 | 1.885 | 1-5/16 | - |
214-216 |
7/8 | 1 - 11-1/2 | - | 0.669 | 2.424 | 1.174 | 1-9/16 | - |
216-216 |
1 | 1 - 11-1/2 | - | 0.844 | 3.76 | 2.3 | 1-5/8 | - |
220-220 |
1-1/4 | 1-1/4 - 11-1/2 | - | 0.937 | 4.395 | 2.48 | 1-3/4 | - |
204-1J-202 |
- | - | - | - | - | - | - | - |
204-1J-202 |
1/4 | 1/8-27 | 1/2 | 0.142 | 2.082 | 1.092 | - | - |
204-1J-204 |
1/4 | 1/4-18 | 11/16 | 0.156 | 2.445 | 1.44 | - | - |
204-1J-206 |
1/4 | 3/8-18 | 13/16 | 0.156 | 2.595 | 1.625 | - | - |
204-1J-208 |
1/4 | 1/2-14 | 7/8 | 0.156 | 2.785 | 1.795 | - | - |
206-1J-204 |
3/8 | 1/4-18 | 11/16 | 0.22 | 2.59 | 1.605 | - | - |
206-1J-206 |
3/8 | 3/8-18 | 13/16 | 0.296 | 2.59 | 1.625 | - | - |
206-1J-208 |
3/8 | 1/2-14 | 7/8 | 0.296 | 2.78 | 1.81 | - | - |
208-1J-206 |
1/2 | 3/8-18 | 1 | 0.296 | 2.835 | 1.605 | - | - |
208-1J-208 |
1/2 | 1/2-14 | 1 | 0.406 | 3.035 | 1.8 | - | - |
210-1J-212 |
5/8 | 3/4-14 | 1-5/16 | 0.5 | 3.08 | 1.855 | - | - |
212-1J-208 |
3/4 | 1/2-14 | 1-5/16 | 0.439 | 3.125 | 1.89 | - | - |
212-1J-212 |
3/4 | 3/4-14 | 1-5/16 | 0.625 | 3.135 | 1.885 | - | - |
216-1J-216 |
1 | 1 - 11-1/2 | 1-5/8 | 0.844 | 3.76 | 2.3 | - | - |
220-1J-220 |
1-1/4 | 1-1/4 - 11-1/2 | 1-3/4 | 0.937 | 4.395 | 2.48 | - | - |
204-1P-202 |
- | - | - | - | - | - | - | - |
204-1P-202 |
1/4 | 1/8-27 | - | 0.156 | 2.082 | 1.092 | 1/2 | - |
204-1P-204 |
1/4 | 1/4-18 | - | 0.156 | 2.445 | 1.44 | 11/16 | - |
204-1P-206 |
1/4 | 3/8-18 | - | 0.156 | 2.595 | 1.625 | 13/16 | - |
204-1P-208 |
1/4 | 1/2-14 | - | 0.156 | 2.785 | 1.795 | 7/8 | - |
206-1P-204 |
3/8 | 1/4-18 | - | 0.296 | 2.59 | 1.605 | 11/16 | - |
206-1P-206 |
3/8 | 3/8-18 | - | 0.296 | 2.59 | 1.625 | 13/16 | - |
206-1P-208 |
3/8 | 1/2-14 | - | 0.296 | 2.78 | 1.81 | 7/8 | - |
208-1P-206 |
1/2 | 3/8-18 | - | 0.406 | 2.835 | 1.605 | 1 | - |
208-1P-208 |
1/2 | 1/2-14 | - | 0.406 | 3.035 | 1.8 | 1 | - |
212-1P-208 |
3/4 | 1/2-14 | - | 0.625 | 3.125 | 1.89 | 1-5/16 | - |
212-1P-212 |
3/4 | 3/4-14 | - | 0.625 | 3.135 | 1.885 | 1-5/16 | - |
216-1P-216 |
1 | 1 - 11-1/2 | - | 0.844 | 3.76 | 2.3 | 1-5/8 | - |
204-KT-202 |
- | - | - | - | - | - | - | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
204-KT-202 |
1/4 | 1/8-27 | - | - | 2.85 | 1.602 | 11/16 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
204-KT-204 |
1/4 | 1/4-18 | - | - | 2.929 | 1.681 | 11/16 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
204-KT-206 |
1/4 | 3/8-18 | - | - | 3.087 | 1.839 | 13/16 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
206-KT-204 |
3/8 | 1/4-18 | - | - | 3.208 | 1.713 | 11/16 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
206-KT-206 |
3/8 | 3/8-18 | - | - | 3.378 | 1.878 | 13/16 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
206-KT-208 |
3/8 | 1/2-14 | - | - | 3.465 | 1.968 | 1 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
208-KT-208 |
1/2 | 1/2-14 | - | - | 3.525 | 2.029 | 1 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
212-KT-212 |
3/4 | 3/4-14 | - | - | 3.795 | 2.205 | 1-3/8 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
216-KT-216 |
1 | 1-11-1/2 | - | - | 4.461 | 2.728 | 1-5/8 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
220-KT-220 |
1-1/4 | 1-1/4-11-1/2 | - | - | 5.138 | 2.76 | 2 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
