| Part Number |
Hose I.D. (in.) | Thread | Stem Hex | Fitting Length | C.O. Cutoff | Nut Hex | Description |
| 204-KT-604 |
1/4" | 7/16"-20 | 0.559 | 2.142 | 0.894 | 0.562 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
| 204-KT-605 |
1/4" | 1/2"-20 | 0.559 | 2.142 | 0.894 | 0.687 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
| 204-KT-606 |
1/4" | 9/16"-18 | 0.559 | 2.142 | 0.894 | 0.750 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
| 206-KT-604 |
3/8" | 7/16"-20 | 0.687 | 2.374 | 0.878 | 0.562 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
| 206-KT-606 |
3/8" | 9/16"-18 | 0.687 | 2.374 | 0.878 | 0.750 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
| 206-KT-608 |
3/8" | 3/4"-16 | 0.875 | 2.472 | 0.976 | 0.875 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
| 206-KT-610 |
3/8" | 7/8"-14 | 0.875 | 2.543 | 1.047 | 1.062 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
| 206-KT-612 |
3/8" | 1-1/16"-12 | 1.125 | 2.551 | 1.055 | 1.250 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
| 208-KT-606 |
1/2" | 9/16"-18 | 0.875 | 2.425 | 0.929 | 0.875 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
| 208-KT-608 |
1/2" | 3/4"-16 | 0.875 | 2.484 | 0.988 | 0.875 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
| 208-KT-610 |
1/2" | 7/8"-14 | 0.875 | 2.504 | 1.008 | 1.062 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
| 208-KT-612 |
1/2" | 1-1/16"-12 | 1.125 | 2.622 | 1.126 | 1.250 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
| 210-KT-608 |
5/8" | 3/4"-16 | 1.181 | 2.677 | 1.177 | 0.875 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
| 210-KT-610 |
5/8" | 7/8"-14 | 1.063 | 2.63 | 1.13 | 1.062 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
| 210-KT-612 |
5/8" | 1-1/16"-12 | 1.063 | 2.63 | 1.13 | 1.250 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
| 212-KT-612 |
3/4" | 1-1/16"-12 | 1.125 | 2.728 | 1.138 | 1.250 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
| 212-KT-610 |
3/4" | 7/8"-14 | 1.125 | 2.717 | 1.126 | 1.062 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
| 212-KT-616 |
3/4" | 1-5/16-12 | 1.378 | 2.934 | 1.344 | 1.500 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
| 216-KT-616 |
1" | 1-5/16"-12 | 1.378 | 3.13 | 1.398 | 1.500 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
| 216-KT-620 |
1" | 1-5/8"-12 | 1.750 | 3.311 | 1.579 | 2.000 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
| 220-KT-620 |
1-1/4" | 1-5/8"-12 | 1.752 | 3.583 | 1.583 | 2.000 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
