| Part Number |
Hose I.D. (in.) | L | O.D. | I.D. | Description | D2 | D19 | L38 | L39 | L40 | S | B UN/UNF-2A | S UN/UNF-24 |
| 503-R5-500 |
3/16 | 1.000 | 0.785 | 0.550 | 1 and 2 Wire Combination Non-Skive Steel Ferrule for SAE 100R1AT, 100R2AT, 100R5, Hydra-Lite I & II | 0.620 | 0.370 | 0.740 | 0.350 | 1.600 | 0.640 | 1-1/16 - 12 | 13/16-12 |
| 503-500 |
3/16 | 1.000 | 0.825 | 0.590 | 1 and 2 Wire Combination Non-Skive Steel Ferrule for SAE 100R1AT, 100R2AT, 100R5, Hydra-Lite I & II | 0.550 | 0.550 | 1.640 | 0.610 | 2.500 | 0.980 | 1-1/16 - 12 | 1-3/16 - 12 |
| 504-500 |
1/4 | 1.000 | .873 | .630 | - | - | - | - | - | - | - | - | - |
| 505-500 |
5/16 | 1.000 | 0.965 | 0.705 | 1 and 2 Wire Combination Non-Skive Steel Ferrule for SAE 100R1AT, 100R2AT, 100R5, Hydra-Lite I & II | 1.020 | 1.020 | 1.840 | 0.690 | 2.800 | 1.460 | 1-5/8 - 12 | 1-11/16 - 12 |
| 506-500 |
3/8 | 1.000 | 1.060 | .793 | - | - | - | - | - | - | - | - | - |
| 508-500 |
1/2 | 1.230 | 1.153 | .905 | - | - | - | - | - | - | - | - | - |
| 508-R5-500 |
1/2 | 1.230 | 1.153 | 0.950 | 1 and 2 Wire Combination Non-Skive Steel Ferrule for SAE 100R1AT, 100R2AT, 100R5, Hydra-Lite I & II | - | - | - | - | - | - | - | - |
| 510-500 |
5/8 | 1.250 | 1.315 | 1.060 | 1 and 2 Wire Combination Non-Skive Steel Ferrule for SAE 100R1AT, 100R2AT, 100R5, Hydra-Lite I & II | - | - | - | - | - | - | - | - |
| 512-500 |
3/4 | 1.470 | 1.531 | 1.211 | - | - | - | - | - | - | - | - | - |
| 514-500 |
7/8 | 1.470 | 1.531 | 1.243 | 1 and 2 Wire Combination Non-Skive Steel Ferrule for SAE 100R1AT, 100R2AT, 100R5, Hydra-Lite I & II | - | - | - | - | - | - | - | - |
| 516-500 |
1 | 1.500 | 1.934 | 1.565 | 1 and 2 Wire Combination Non-Skive Steel Ferrule for SAE 100R1AT, 100R2AT, 100R5, Hydra-Lite I & II | - | - | - | - | - | - | - | - |
| 520-500 |
1-1/4 | 2.210 | 2.375 | 1.940 | 1 and 2 Wire Combination Non-Skive Steel Ferrule for SAE 100R1AT, 100R2AT, 100R5, Hydra-Lite I & II | - | - | - | - | - | - | - | - |
| 524-500 |
1-1/2 | 2.390 | 2.687 | 2.253 | 1 and 2 Wire Combination Non-Skive Steel Ferrule for SAE 100R1AT, 100R2AT, 100R5, Hydra-Lite I & II | - | - | - | - | - | - | - | - |
| 532-500 |
2 | 3.200 | 3.250 | 2.755 | 1 and 2 Wire Combination Non-Skive Steel Ferrule for SAE 100R1AT, 100R2AT, 100R5, Hydra-Lite I & II | - | - | - | - | - | - | - | - |
| 532-R5-500 |
2-3/8 | 3.200 | 3.255 | 2.910 | 1 and 2 Wire Combination Non-Skive Steel Ferrule for SAE 100R1AT, 100R2AT, 100R5, Hydra-Lite I & II | - | - | - | - | - | - | - | - |
| 504-500 |
1/4 | 1.043 | 0.873 | 0.630 | - | 0.780 | 0.780 | 1.750 | 0.640 | 2.660 | 1.160 | 1-5/26-12 | 1-7/16-12 |
