Part Number |
Hose I.D. (in.) | Thread | Stem Hex | Fitting Length | C.O. Cutoff | Drop | Description |
204-KTS-684 |
1/4" | 7/16"-20 | 0.562 | 2.572 | 1.324 | 0.433 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
204-KTS-685 |
1/4" | 1/2"-20 | 0.687 | 2.572 | 1.324 | 0.433 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
204-KTS-686 |
1/4" | 9/16"-18 | 0.750 | 2.572 | 1.324 | 0.433 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
206-KTS-686 |
3/8" | 9/16"-18 | 0.750 | 2.913 | 1.417 | 0.433 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
206-KTS-688 |
3/8" | 3/4"-16 | 0.875 | 3.031 | 1.535 | 0.512 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
208-KTS-688 |
1/2" | 3/4"-16 | 0.875 | 3.274 | 1.778 | 0.591 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
208-KTS-690 |
1/2" | 7/8"-14 | 1.062 | 3.274 | 1.778 | 0.591 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
210-KTS-690 |
5/8" | 7/8"-14 | 1.062 | 3.413 | 1.913 | 0.630 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
212-KTS-692 |
3/4" | 1-1/16"-12 | 1.250 | 4.138 | 2.547 | 0.827 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
212-KTS-696 |
3/4" | 1-5/16"-12 | 1.500 | 4.22 | 2.63 | 0.909 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
216-KTS-696 |
1" | 1-5/16"-12 | 1.500 | 5.067 | 3.334 | 1.181 | For compression style crimpers, one and two wire braided fittings for one and two wire braided hoses |
