Part Number |
Hose I.D. (in.) | Hose O.D. (in.) | Rated W.P. (psi) | Min. Burst (psi) | Min. Bend Radius (in.) | Wt. Per Ft. (lbs) | Recommended for | Tube | Reinforcement | Cover | Temperature | Recommended Couplings | Lengths | Premium Features | D1(2) | D1(3) | I2 | L7 | L7(2) | L7(3) | L15 | S2 | S4 | S4(2) |
1213-12CR |
0.750 | 1.263 | 5000 | 20000 | 4.75 | 1.07 | Extra high pressure hydraulic oil lines for heavy duty service applications with crude oils, fuel oils, lubricating oils, and gasoline. Exceeds SAE 100R13 performance and half the bend radius. | Black, oil resistant, Neoprene (CR) | Multiple plies of spirally-wrapped high tensile steel wire. | Black ultra high abrasion compound which is weather and oil resistant. MSHA approved. Red mylar layline. | -40°F to +250°F | 1W, 1Y | Hose supplied in random lengths | 1. Ultra high abrasion resistant cover 2. Half bend radius flexibility 3. High impulse life | 0.810 | 0.810 | - | 1.640 | 1.640 | 1.640 | - | 1.440 | - | - |
1213-16CR |
1 | 1.524 | 5000 | 20000 | 6 | 1.48 | Extra high pressure hydraulic oil lines for heavy duty service applications with crude oils, fuel oils, lubricating oils, and gasoline. Exceeds SAE 100R13 performance and half the bend radius. | Black, oil resistant, Neoprene (CR) | Multiple plies of spirally-wrapped high tensile steel wire. | Black ultra high abrasion compound which is weather and oil resistant. MSHA approved. Red mylar layline. | -40°F to +250°F | 1W, 1Y | Hose supplied in random lengths | 1. Ultra high abrasion resistant cover 2. Half bend radius flexibility 3. High impulse life | 1.020 | 1.020 | - | 1.760 | 1.760 | 1.760 | - | 1.610 | - | - |
1213-20CR |
1-1/4 | 1.962 | 5000 | 20000 | 8.25 | 2.48 | Extra high pressure hydraulic oil lines for heavy duty service applications with crude oils, fuel oils, lubricating oils, and gasoline. Exceeds SAE 100R13 performance and half the bend radius. | Black, oil resistant, Neoprene (CR) | Multiple plies of spirally-wrapped high tensile steel wire. | Black ultra high abrasion compound which is weather and oil resistant. MSHA approved. Red mylar layline. | -40°F to +250°F | 1W, 1Y | Hose supplied in random lengths | 1. Ultra high abrasion resistant cover 2. Half bend radius flexibility 3. High impulse life | 1.260 | 1.260 | - | 1.920 | 1.920 | 1.920 | - | 1.970 | - | - |
1213-24CR |
1-1/2 | 2.256 | 5000 | 20000 | 10 | 3.22 | Extra high pressure hydraulic oil lines for heavy duty service applications with crude oils, fuel oils, lubricating oils, and gasoline. Exceeds SAE 100R13 performance and half the bend radius. | Black, oil resistant, Neoprene (CR) | Multiple plies of spirally-wrapped high tensile steel wire. | Black ultra high abrasion compound which is weather and oil resistant. MSHA approved. Red mylar layline. | -40°F to +250°F | 1W, 1Y | Hose supplied in random lengths | 1. Ultra high abrasion resistant cover 2. Half bend radius flexibility 3. High impulse life | - | - | - | - | - | - | - | - | - | - |
1213-32CR |
2 | 2.8 | 5000 | 20000 | 25 | 5.03 | Extra high pressure hydraulic oil lines for heavy duty service applications with crude oils, fuel oils, lubricating oils, and gasoline. Exceeds SAE 100R13 performance and half the bend radius. | Black, oil resistant, Neoprene (CR) | Multiple plies of spirally-wrapped high tensile steel wire. | Black ultra high abrasion compound which is weather and oil resistant. MSHA approved. Red mylar layline. | -40°F to +250°F | 1W, 1Y | Hose supplied in random lengths | 1. Ultra high abrasion resistant cover 2. Half bend radius flexibility 3. High impulse life | 0.170 | - | 1.240 | - | - | - | 1.900 | - | 0.810 | 0.810 |
