Part Number |
Hose I.D. (in.) | Hose O.D. (in.) | Rated W.P. (psi) | Min. Burst (psi) | Min. Bend Radius (in.) | Wt. Per Ft. (lbs) | Recommended for | Tube | Reinforcement | Cover | Temperature | Recommended Couplings | Din Tube O.D. (MM) | D1(2) | D17 | I2 | I4 | L16 | L17 | S2 | S4 |
1311-06 |
3/8 | 0.86 | 6090 | 24360 | 5.91 | 0.538 | Use with petroleum base hydraulic fluids within a temperature range of -40°F- +250°F | Oil resistant synthetic rubber | Multiple spiral plies of heavy steel wire wrapped in altenating directions | Oil and weather resistant synthetic rubber. White mylar layline | -40°F to 250°F | 1Y | 12 | 0.610 | 1.370 | 1.590 | 0.060 | 1.520 | 2.650 | 1.190 | 1.500 |
1311-08 |
1/2 | 1 | 6090 | 24360 | 7.87 | 0.605 | Use with petroleum base hydraulic fluids within a temperature range of -40°F- +250°F | Oil resistant synthetic rubber | Multiple spiral plies of heavy steel wire wrapped in altenating directions | Oil and weather resistant synthetic rubber. White mylar layline | -40°F to 250°F | 1Y | 15 | 0.810 | 1.620 | 1.610 | 0.060 | 1.670 | 2.800 | 1.440 | 1.750 |
1311-12 |
3/4 | 1.36 | 6090 | 24360 | 10.4 | 1.243 | Use with petroleum base hydraulic fluids within a temperature range of -40°F- +250°F | Oil resistant synthetic rubber | Multiple spiral plies of heavy steel wire wrapped in altenating directions | Oil and weather resistant synthetic rubber. White mylar layline | -40°F to 250°F | 1Y | 16 | 0.810 | 1.620 | 1.600 | 0.060 | 1.790 | 2.970 | 1.610 | 1.750 |
1311-16 |
1 | 1.61 | 6090 | 24360 | 13 | 1.949 | Use with petroleum base hydraulic fluids within a temperature range of -40°F- +250°F | Oil resistant synthetic rubber | Multiple spiral plies of heavy steel wire wrapped in altenating directions | Oil and weather resistant synthetic rubber. White mylar layline | -40°F to 250°F | 1Y | 12 | 1.020 | 1.870 | 1.660 | 0.060 | 1.790 | 2.970 | 1.610 | 2.000 |
1311-20 |
1-1/4 | 1.96 | 6090 | 24360 | 17.52 | 2.822 | Use with petroleum base hydraulic fluids within a temperature range of -40°F- +250°F | Oil resistant synthetic rubber | Multiple spiral plies of heavy steel wire wrapped in altenating directions | Oil and weather resistant synthetic rubber. White mylar layline | -40°F to 250°F | 1Y | 15 | 1.260 | 2.190 | 1.660 | 0.060 | 1.950 | 3.130 | 1.870 | 2.380 |
1311-24 |
1-1/2 | 2.28 | 6090 | 24360 | 20.87 | 3.763 | Use with petroleum base hydraulic fluids within a temperature range of -40°F- +250°F | Oil resistant synthetic rubber | Multiple spiral plies of heavy steel wire wrapped in altenating directions | Oil and weather resistant synthetic rubber. White mylar layline | -40°F to 250°F | 1Y | 18 | - | - | - | - | - | - | - | - |
1311-32 |
2 | 2.76 | 6090 | 24360 | 23.62 | 4.442 | Use with petroleum base hydraulic fluids within a temperature range of -40°F- +250°F | Oil resistant synthetic rubber | Multiple spiral plies of heavy steel wire wrapped in altenating directions | Oil and weather resistant synthetic rubber. White mylar layline | -40°F to 250°F | 1Y | 15 | 0.170 | 0.690 | 1.240 | 0.060 | 0.890 | 1.850 | 0.560 | 0.810 |
