| Part Number |
Hose I.D. (in.) | Hose O.D. (in.) | Rated W.P. (psi) | Min. Burst (psi) | Min. Bend Radius (in.) | Wt. Per Ft. (lbs) | Recommended for | Tube | Reinforcement | Cover | Temperature | D20 | L8 | L9 | S5 | N UN/UNF-2A |
| A012-03 |
0 3/16 | 0.5 | 3000 | 12000 | 3.5 | 0.14 | Applications which meet or exceed SAE 100R1 Typa A. Medium pressure hydraulic oil lines. | Black, oil resistant Nitrile (NBR) | One wire braid of high tensile steel | Black, oil and abrasion resistant Neoprene (CR). MSHA approved | -65°F to 250°F | 0.480 | 1.990 | 1.360 | 1.250 | 7/8-14 |
| A012-04 |
0 1/4 | 0.62 | 2750 | 11000 | 4 | 0.21 | Applications which meet or exceed SAE 100R1 Typa A. Medium pressure hydraulic oil lines. | Black, oil resistant Nitrile (NBR) | One wire braid of high tensile steel | Black, oil and abrasion resistant Neoprene (CR). MSHA approved | -65°F to 250°F | 0.610 | 1.920 | 1.190 | 1.250 | 1-1/16 - 12 |
| A012-05 |
0 5/16 | 0.69 | 2500 | 10000 | 4.5 | 0.23 | Applications which meet or exceed SAE 100R1 Typa A. Medium pressure hydraulic oil lines. | Black, oil resistant Nitrile (NBR) | One wire braid of high tensile steel | Black, oil and abrasion resistant Neoprene (CR). MSHA approved | -65°F to 250°F | 0.610 | 1.960 | 1.230 | 1.500 | 1-5/16 - 12 |
| A012-06 |
0 3/8 | 0.78 | 2250 | 9000 | 5 | 0.28 | Applications which meet or exceed SAE 100R1 Typa A. Medium pressure hydraulic oil lines. | Black, oil resistant Nitrile (NBR) | One wire braid of high tensile steel | Black, oil and abrasion resistant Neoprene (CR). MSHA approved | -65°F to 250°F | 0.490 | 2.040 | 1.410 | 1.500 | 7/8-14 |
| A012-08 |
0 1/2 | 0.9 | 2000 | 8000 | 7 | 0.35 | Applications which meet or exceed SAE 100R1 Typa A. Medium pressure hydraulic oil lines. | Black, oil resistant Nitrile (NBR) | One wire braid of high tensile steel | Black, oil and abrasion resistant Neoprene (CR). MSHA approved | -65°F to 250°F | 0.610 | 2.140 | 1.410 | 1.500 | 1-1/16 - 12 |
| A012-10 |
0 5/8 | 1.03 | 1500 | 6000 | 8 | 0.42 | Applications which meet or exceed SAE 100R1 Typa A. Medium pressure hydraulic oil lines. | Black, oil resistant Nitrile (NBR) | One wire braid of high tensile steel | Black, oil and abrasion resistant Neoprene (CR). MSHA approved | -65°F to 250°F | 0.810 | 1.990 | 1.260 | 1.500 | 1-5/16 - 12 |
| A012-12 |
0 3/4 | 1.18 | 1250 | 5000 | 9.5 | 0.5 | Applications which meet or exceed SAE 100R1 Typa A. Medium pressure hydraulic oil lines. | Black, oil resistant Nitrile (NBR) | One wire braid of high tensile steel | Black, oil and abrasion resistant Neoprene (CR). MSHA approved | -65°F to 250°F | 0.810 | 2.060 | 1.330 | 1.880 | 1-5/8 - 12 |
| A012-16 |
1 | 1.49 | 1000 | 4000 | 12 | 0.73 | Applications which meet or exceed SAE 100R1 Typa A. Medium pressure hydraulic oil lines. | Black, oil resistant Nitrile (NBR) | One wire braid of high tensile steel | Black, oil and abrasion resistant Neoprene (CR). MSHA approved | -65°F to 250°F | 0.840 | 2.280 | 1.550 | 1.750 | 1-5/16 - 12 |
| 1012-20 |
1-1/4 | 1.8 | 625 | 2500 | 16.5 | 1.03 | Applications which meet or exceed SAE 100R1 Typa A. Medium pressure hydraulic oil lines. | Black, oil resistant Nitrile (NBR) | One wire braid of high tensile steel | Black, oil and abrasion resistant Neoprene (CR). MSHA approved | -65°F to 250°F | 1.020 | 2.060 | 1.330 | 1.880 | 1-5/8 - 12 |
| 1012-24 |
1-1/2 | 2.06 | 500 | 2000 | 20 | 1.18 | Applications which meet or exceed SAE 100R1 Typa A. Medium pressure hydraulic oil lines. | Black, oil resistant Nitrile (NBR) | One wire braid of high tensile steel | Black, oil and abrasion resistant Neoprene (CR). MSHA approved | -65°F to 250°F | 1.020 | 2.130 | 1.400 | 2.130 | 1-7/8 - 12 |
| 1012-32 |
2 | 2.63 | 375 | 1500 | 25 | 1.65 | Applications which meet or exceed SAE 100R1 Typa A. Medium pressure hydraulic oil lines. | Black, oil resistant Nitrile (NBR) | One wire braid of high tensile steel | Black, oil and abrasion resistant Neoprene (CR). MSHA approved | -65°F to 250°F | 1.080 | 2.350 | 1.620 | 2.130 | 1-5/8 - 12 |
