Part Number |
Hose I.D. (in.) | Hose O.D. (in.) | Rated W.P. (psi) | Min. Burst (psi) | Min. Bend Radius (in.) | Wt. Per Ft. (lbs) | Rated Suction (in./hg.) | Recommended for | Tube | Reinforcement | Cover | Temperature | D2 | S1 | NPTF |
2004-12 |
0 3/4 | 1.24 | 300 | 1200 | 5 | 0.42 | 25.0 | Petroleum and water based hydraulic fluids, in low pressure and vacuum service. Especially recommended for return lines in hydraulic control systems. Meets or exceeds requirements of SAE 100R4 | Black, oil resistant, Nitrile (NBR) | Two textile braids, pre-treated for tube and cover adhesion. Helix wires are located between the braids to resist collapse under vacuum or bending. | Black, oil and abrasion resistant Neoprene (CR). MSHA approved. | -40°F to +200°F | 0.260 | 0.750 | 1/4-18 |
2004-16 |
1 | 1.53 | 250 | 1000 | 6 | 0.57 | 25.0 | Petroleum and water based hydraulic fluids, in low pressure and vacuum service. Especially recommended for return lines in hydraulic control systems. Meets or exceeds requirements of SAE 100R4 | Black, oil resistant, Nitrile (NBR) | Two textile braids, pre-treated for tube and cover adhesion. Helix wires are located between the braids to resist collapse under vacuum or bending. | Black, oil and abrasion resistant Neoprene (CR). MSHA approved. | -40°F to +200°F | 0.260 | 0.750 | 3/8-18 |
2004-20 |
1-1/4 | 1.78 | 200 | 800 | 8 | 0.67 | 25.0 | Petroleum and water based hydraulic fluids, in low pressure and vacuum service. Especially recommended for return lines in hydraulic control systems. Meets or exceeds requirements of SAE 100R4 | Black, oil resistant, Nitrile (NBR) | Two textile braids, pre-treated for tube and cover adhesion. Helix wires are located between the braids to resist collapse under vacuum or bending. | Black, oil and abrasion resistant Neoprene (CR). MSHA approved. | -40°F to +200°F | 0.260 | 0.880 | 1/2-14 |
2004-24 |
1-1/2 | 2.07 | 150 | 600 | 10 | 0.84 | 25.0 | Petroleum and water based hydraulic fluids, in low pressure and vacuum service. Especially recommended for return lines in hydraulic control systems. Meets or exceeds requirements of SAE 100R4 | Black, oil resistant, Nitrile (NBR) | Two textile braids, pre-treated for tube and cover adhesion. Helix wires are located between the braids to resist collapse under vacuum or bending. | Black, oil and abrasion resistant Neoprene (CR). MSHA approved. | -40°F to +200°F | 0.380 | 0.880 | 3/8-18 |
2004-32 |
2 | 2.54 | 100 | 400 | 12 | 1.03 | 25.0 | Petroleum and water based hydraulic fluids, in low pressure and vacuum service. Especially recommended for return lines in hydraulic control systems. Meets or exceeds requirements of SAE 100R4 | Black, oil resistant, Nitrile (NBR) | Two textile braids, pre-treated for tube and cover adhesion. Helix wires are located between the braids to resist collapse under vacuum or bending. | Black, oil and abrasion resistant Neoprene (CR). MSHA approved. | -40°F to +200°F | 0.380 | 0.880 | 1/2-14 |
2004-40 |
2-1/2 | 3.12 | 62 | 250 | 14 | 1.7 | 25.0 | Petroleum and water based hydraulic fluids, in low pressure and vacuum service. Especially recommended for return lines in hydraulic control systems. Meets or exceeds requirements of SAE 100R4 | Black, oil resistant, Nitrile (NBR) | Two textile braids, pre-treated for tube and cover adhesion. Helix wires are located between the braids to resist collapse under vacuum or bending. | Black, oil and abrasion resistant Neoprene (CR). MSHA approved. | -40°F to +200°F | 0.380 | 1.130 | 3/4-14 |
2004-48 |
3 | 3.62 | 56 | 225 | 18 | 1.98 | 25.0 | Petroleum and water based hydraulic fluids, in low pressure and vacuum service. Especially recommended for return lines in hydraulic control systems. Meets or exceeds requirements of SAE 100R4 | Black, oil resistant, Nitrile (NBR) | Two textile braids, pre-treated for tube and cover adhesion. Helix wires are located between the braids to resist collapse under vacuum or bending. | Black, oil and abrasion resistant Neoprene (CR). MSHA approved. | -40°F to +200°F | 0.480 | 1.060 | 1/2-14 |
2004-56 |
3-1/2 | 4.14 | 45 | 180 | 21 | 2.34 | 25.0 | Petroleum and water based hydraulic fluids, in low pressure and vacuum service. Especially recommended for return lines in hydraulic control systems. Meets or exceeds requirements of SAE 100R4 | Black, oil resistant, Nitrile (NBR) | Two textile braids, pre-treated for tube and cover adhesion. Helix wires are located between the braids to resist collapse under vacuum or bending. | Black, oil and abrasion resistant Neoprene (CR). MSHA approved. | -40°F to +200°F | 0.480 | 1.130 | 3/4-14 |
2004-64 |
4 | 4.7 | 35 | 140 | 24 | 3.03 | 25.0 | Petroleum and water based hydraulic fluids, in low pressure and vacuum service. Especially recommended for return lines in hydraulic control systems. Meets or exceeds requirements of SAE 100R4 | Black, oil resistant, Nitrile (NBR) | Two textile braids, pre-treated for tube and cover adhesion. Helix wires are located between the braids to resist collapse under vacuum or bending. | Black, oil and abrasion resistant Neoprene (CR). MSHA approved. | -40°F to +200°F | 0.530 | 1.250 | 1/2-14 |
