Product Variations
Part Number | Hose I.D. (in.) | Hose O.D. (in.) | Rated W.P. (psi) | Min. Burst (psi) | Min. Bend Radius (in.) | Wt. Per Ft. (lbs) | Recommended for | Tube | Reinforcement | Cover | Temperature | D8 | L36 |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|
A005-04 | 3/16 | 0.52 | 3000 | 12000 | 3 | 0.16 | Medium pressure hydraulic applications using petroleum based hydraulic fluids. Also for gasoline, water, air and truck air brake applications. Meets and excees the requirements of SAE 100R5 and SAE J1402 type AII for hydraulic service in all sizes. Meets and exceeds the requirements of DOT FMVSS 106 type A11 for the truck air brake applications in sizes 3/16' thru 5/8". Also approved by AAMVA for air brake service. | Black, oil resistant, high temperature Nitrile (NBR) | One high tensile steel wire braid over one polyester braid. Friction layers under and over wire braid to improve tube and cover adhesion. | Oil resistant polyester braid impregnated with Neoprene (CR). | -40°F to +275°F; +300°F intermittent. | 0.620 | 0.770 |
A005-05 | 1/4 | 0.58 | 3000 | 12000 | 3.38 | 0.18 | Medium pressure hydraulic applications using petroleum based hydraulic fluids. Also for gasoline, water, air and truck air brake applications. Meets and excees the requirements of SAE 100R5 and SAE J1402 type AII for hydraulic service in all sizes. Meets and exceeds the requirements of DOT FMVSS 106 type A11 for the truck air brake applications in sizes 3/16' thru 5/8". Also approved by AAMVA for air brake service. | Black, oil resistant, high temperature Nitrile (NBR) | One high tensile steel wire braid over one polyester braid. Friction layers under and over wire braid to improve tube and cover adhesion. | Oil resistant polyester braid impregnated with Neoprene (CR). | -40°F to +275°F; +300°F intermittent. | 0.750 | 0.860 |
A005-06 | 5/16 | 0.67 | 2250 | 9000 | 4 | 0.23 | Medium pressure hydraulic applications using petroleum based hydraulic fluids. Also for gasoline, water, air and truck air brake applications. Meets and excees the requirements of SAE 100R5 and SAE J1402 type AII for hydraulic service in all sizes. Meets and exceeds the requirements of DOT FMVSS 106 type A11 for the truck air brake applications in sizes 3/16' thru 5/8". Also approved by AAMVA for air brake service. | Black, oil resistant, high temperature Nitrile (NBR) | One high tensile steel wire braid over one polyester braid. Friction layers under and over wire braid to improve tube and cover adhesion. | Oil resistant polyester braid impregnated with Neoprene (CR). | -40°F to +275°F; +300°F intermittent. | 0.750 | 0.880 |
A005-08 | 13/32 | 0.77 | 2000 | 8000 | 4.62 | 0.27 | Medium pressure hydraulic applications using petroleum based hydraulic fluids. Also for gasoline, water, air and truck air brake applications. Meets and excees the requirements of SAE 100R5 and SAE J1402 type AII for hydraulic service in all sizes. Meets and exceeds the requirements of DOT FMVSS 106 type A11 for the truck air brake applications in sizes 3/16' thru 5/8". Also approved by AAMVA for air brake service. | Black, oil resistant, high temperature Nitrile (NBR) | One high tensile steel wire braid over one polyester braid. Friction layers under and over wire braid to improve tube and cover adhesion. | Oil resistant polyester braid impregnated with Neoprene (CR). | -40°F to +275°F; +300°F intermittent. | 0.920 | 0.900 |
A005-10 | 1/2 | 0.92 | 1750 | 7000 | 5.5 | 0.36 | Medium pressure hydraulic applications using petroleum based hydraulic fluids. Also for gasoline, water, air and truck air brake applications. Meets and excees the requirements of SAE 100R5 and SAE J1402 type AII for hydraulic service in all sizes. Meets and exceeds the requirements of DOT FMVSS 106 type A11 for the truck air brake applications in sizes 3/16' thru 5/8". Also approved by AAMVA for air brake service. | Black, oil resistant, high temperature Nitrile (NBR) | One high tensile steel wire braid over one polyester braid. Friction layers under and over wire braid to improve tube and cover adhesion. | Oil resistant polyester braid impregnated with Neoprene (CR). | -40°F to +275°F; +300°F intermittent. | 0.920 | 0.950 |
A005-12 | 5/8 | 1.08 | 1500 | 6000 | 6.5 | 0.44 | Medium pressure hydraulic applications using petroleum based hydraulic fluids. Also for gasoline, water, air and truck air brake applications. Meets and excees the requirements of SAE 100R5 and SAE J1402 type AII for hydraulic service in all sizes. Meets and exceeds the requirements of DOT FMVSS 106 type A11 for the truck air brake applications in sizes 3/16' thru 5/8". Also approved by AAMVA for air brake service. | Black, oil resistant, high temperature Nitrile (NBR) | One high tensile steel wire braid over one polyester braid. Friction layers under and over wire braid to improve tube and cover adhesion. | Oil resistant polyester braid impregnated with Neoprene (CR). | -40°F to +275°F; +300°F intermittent. | 0.920 | 1.010 |
1005-16 | 7/8 | 1.23 | 800 | 3200 | 7.38 | 0.45 | Medium pressure hydraulic applications using petroleum based hydraulic fluids. Also for gasoline, water, air and truck air brake applications. Meets and excees the requirements of SAE 100R5 and SAE J1402 type AII for hydraulic service in all sizes. Meets and exceeds the requirements of DOT FMVSS 106 type A11 for the truck air brake applications in sizes 3/16' thru 5/8". Also approved by AAMVA for air brake service. | Black, oil resistant, high temperature Nitrile (NBR) | One high tensile steel wire braid over one polyester braid. Friction layers under and over wire braid to improve tube and cover adhesion. | Oil resistant polyester braid impregnated with Neoprene (CR). | -40°F to +275°F; +300°F intermittent. | 1.100 | 0.980 |
1005-20 | 1-1/8 | 1.5 | 625 | 2500 | 9 | 0.56 | Medium pressure hydraulic applications using petroleum based hydraulic fluids. Also for gasoline, water, air and truck air brake applications. Meets and excees the requirements of SAE 100R5 and SAE J1402 type AII for hydraulic service in all sizes. Meets and exceeds the requirements of DOT FMVSS 106 type A11 for the truck air brake applications in sizes 3/16' thru 5/8". Also approved by AAMVA for air brake service. | Black, oil resistant, high temperature Nitrile (NBR) | One high tensile steel wire braid over one polyester braid. Friction layers under and over wire braid to improve tube and cover adhesion. | Oil resistant polyester braid impregnated with Neoprene (CR). | -40°F to +275°F; +300°F intermittent. | 1.100 | 1.030 |
1005-24 | 1-3/8 | 1.75 | 500 | 2000 | 10.5 | 0.64 | Medium pressure hydraulic applications using petroleum based hydraulic fluids. Also for gasoline, water, air and truck air brake applications. Meets and excees the requirements of SAE 100R5 and SAE J1402 type AII for hydraulic service in all sizes. Meets and exceeds the requirements of DOT FMVSS 106 type A11 for the truck air brake applications in sizes 3/16' thru 5/8". Also approved by AAMVA for air brake service. | Black, oil resistant, high temperature Nitrile (NBR) | One high tensile steel wire braid over one polyester braid. Friction layers under and over wire braid to improve tube and cover adhesion. | Oil resistant polyester braid impregnated with Neoprene (CR). | -40°F to +275°F; +300°F intermittent. | 1.100 | 1.090 |
1005-32 | 1-13/16 | 2.22 | 350 | 1400 | 13.25 | 0.83 | Medium pressure hydraulic applications using petroleum based hydraulic fluids. Also for gasoline, water, air and truck air brake applications. Meets and excees the requirements of SAE 100R5 and SAE J1402 type AII for hydraulic service in all sizes. Meets and exceeds the requirements of DOT FMVSS 106 type A11 for the truck air brake applications in sizes 3/16' thru 5/8". Also approved by AAMVA for air brake service. | Black, oil resistant, high temperature Nitrile (NBR) | One high tensile steel wire braid over one polyester braid. Friction layers under and over wire braid to improve tube and cover adhesion. | Oil resistant polyester braid impregnated with Neoprene (CR). | -40°F to +275°F; +300°F intermittent. | 1.350 | 1.150 |
1005-40 | 2-3/8 | 2.88 | 350 | 1400 | 24 | 1.3 | Medium pressure hydraulic applications using petroleum based hydraulic fluids. Also for gasoline, water, air and truck air brake applications. Meets and excees the requirements of SAE 100R5 and SAE J1402 type AII for hydraulic service in all sizes. Meets and exceeds the requirements of DOT FMVSS 106 type A11 for the truck air brake applications in sizes 3/16' thru 5/8". Also approved by AAMVA for air brake service. | Black, oil resistant, high temperature Nitrile (NBR) | One high tensile steel wire braid over one polyester braid. Friction layers under and over wire braid to improve tube and cover adhesion. | Oil resistant polyester braid impregnated with Neoprene (CR). | -40°F to +275°F; +300°F intermittent. | 1.090 | 1.160 |
